HB404L木工鉆床(四排鉆)
Drilling maohine (four-rov drill）
產品(pin)參數
| 設備型號 | HB404L |
|---|---|
水平鉆(zhan)軸最(zui)大間距 Max.width of workpiece | 2450mm |
| 水平鉆軸最大間距 Max.distance of two horizontal drilling head | 640mm |
垂直鉆(zhan)排最(zui)小間(jian)距 Max.thickness of workpiece | 128mm |
| 最大工件厚度 Max.thickness of workpiece | 78mm |
水平(ping)最大鉆孔深(shen)度 Max.depth of horizontal drilling head | 40mm |
垂(chui)直最大鉆孔深度 Max.depth of vertical drilling head | 70mm |
鉆軸轉速(su) Rotating speed of drilling spindles | 2800rpm(50HZ) |
垂直箱功率(lv) Vertical box power | |
| 垂直鉆排功率 Vertical drilling power | 1.5kw |
水平鉆排(pai)功率(lv) Horizontal drilling power | 1.5kw |
工作(zuo)氣壓(ya) Working pressure | 0.6-0.8Mpa |
機械尺寸(mm) Dimension of machine | 3450x2500x1800mm |
裝箱尺寸(mm) Packing size | 3550x1350x1800mm |
注:本(ben)司對(dui)產品規格(ge)及(ji)設計(ji)細節不斷改(gai)良更新,上述功(gong)能與參(can)數可能有優化改(gai)進,請與授權銷售單位確認(ren)。
The company's product spelt elirs and design detals wil be updated continously, The above specifications subject to change without notice,plerse confirm wth authorized distributor.
