HB303L木工鉆床(佐排鉆)
Drilling rnachine (three-row drilt)
產品(pin)參數
| 設備型號 | HB305i |
|---|---|
水(shui)平鉆軸最大間距 Max.width of workpiece | 1850mm |
| 水平鉆軸最大間距 Max.distance of two horizontal drilling head | 640mm |
垂直(zhi)鉆排(pai)最小(xiao)間距 Max.thickness of workpiece | 128mm |
| 最大工件厚度 Max.thickness of workpiece | 78mm |
水平(ping)最大鉆孔深度 Max.depth of horizontal drilling head | 40mm |
垂(chui)直最大(da)鉆孔深度 Max.depth of vertical drilling head | 70mm |
鉆(zhan)軸轉速 Rotating speed of drilling spindles | 2800rpm(50HZ) |
垂直(zhi)箱功率(lv) Vertical box power | |
| 垂直鉆排功率 Vertical drilling power | 1.1kw x 2 |
水平鉆(zhan)排功率 Horizontal drilling power | 1.5kw |
工作氣壓(ya) Working pressure | 0.6-0.8Mpa |
機械尺寸(mm) Dimension of machine | 2700x2500x1760mm |
裝箱尺寸(mm) Packing size | 2750x1350x1800mm |
注:本司對產(chan)品規格及(ji)設計細節不斷(duan)改(gai)良更(geng)新,上述功(gong)能與參數(shu)可能有(you)優(you)化(hua)改(gai)進,請與授權銷售單位確認。
The company's product spelt elirs and design detals wil be updated continously, The above specifications subject to change without notice,plerse confirm wth authorized distributor.
