HB303L木工鉆床(佐排鉆)
Drilling rnachine (three-row drilt)
產品參數
| 設備型號 | HB303L |
|---|---|
水平鉆(zhan)軸最大間距 Max.width of workpiece | 2450mm |
| 水平鉆軸最大間距 Max.distance of two horizontal drilling head | 640mm |
垂直鉆排(pai)最小間距 Max.thickness of workpiece | 128mm |
| 最大工件厚度 Max.thickness of workpiece | 78mm |
水平最大鉆孔深度 Max.depth of horizontal drilling head | 40mm |
垂直(zhi)最大鉆孔深度 Max.depth of vertical drilling head | 70mm |
鉆軸轉速 Rotating speed of drilling spindles | 2800rpm(50HZ) |
垂直箱功率 Vertical box power | |
| 垂直鉆排功率 Vertical drilling power | 1.5kw |
水平鉆排功率 Horizontal drilling power | 1.5kw |
工作氣壓 Working pressure | 0.6-0.8Mpa |
機械尺(chi)寸(cun)(mm) Dimension of machine | 3450x2500x1800mm |
裝箱尺寸(mm) Packing size | 3550x1350x1800mm |
注:本(ben)司對(dui)產品規格及(ji)設計(ji)細(xi)節不(bu)斷改良(liang)更新,上述功能與參(can)數可能有優(you)化改進,請與授權銷售單位(wei)確認。
The company's product spelt elirs and design detals wil be updated continously, The above specifications subject to change without notice,plerse confirm wth authorized distributor.
